Public Types | |
| enum class | OptType { FULL , SHORT } |
Public Member Functions | |
| virtual deluge::vector< std::string_view > | getOptions (OptType optType=OptType::FULL)=0 |
| void | drawValue () override |
| void | drawPixelsForOled () override |
| Paints the pixels below the standard title block. | |
| size_t | size () override |
| virtual bool | isToggle () |
| void | displayToggleValue () |
| void | renderSubmenuItemTypeForOled (int32_t yPixel) override |
| void | toggleValue () |
| MenuItem * | selectButtonPress () override |
| Handle a select button press. | |
| bool | getToggleValue () |
| uint8_t | shouldDrawDotOnName () override |
| Get the "draw dot state". | |
| Public Member Functions inherited from deluge::gui::menu_item::Enumeration | |
| void | beginSession (MenuItem *navigatedBackwardFrom) override |
| Begin an editing session with this menu item. | |
| void | selectEncoderAction (int32_t offset) override |
| Handle select encoder movement. | |
| virtual bool | wrapAround () |
| Should this menu wrap around? | |
| void | renderInHorizontalMenu (int32_t startX, int32_t width, int32_t startY, int32_t height) override |
| Public Member Functions inherited from deluge::gui::menu_item::Value< int32_t > | |
| MenuItem () | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| void | beginSession (MenuItem *navigatedBackwardFrom) override |
| Begin an editing session with this menu item. | |
| void | selectEncoderAction (int32_t offset) override |
| Handle select encoder movement. | |
| void | readValueAgain () override |
| Re-read the value from the system and redraw the display to match. | |
| bool | selectEncoderActionEditsInstrument () final |
| Used by the sound editor to mark the current instrument as edited when the select encoder is scrolled. | |
| void | setValue (int32_t value) |
| int32_t | getValue () |
| Public Member Functions inherited from MenuItem | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| MenuItem & | operator= (const MenuItem &other)=delete |
| MenuItem & | operator= (const MenuItem &&other)=delete |
| virtual ActionResult | buttonAction (deluge::hid::Button b, bool on, bool inCardRoutine) |
| Handle an arbitrary button. | |
| virtual void | horizontalEncoderAction (int32_t offset) |
| Handle horizontal encoder movement. | |
| virtual void | verticalEncoderAction (int32_t offset) |
| Handle vertical encoder movement. | |
| virtual ActionResult | timerCallback () |
| Handle a TimerName::UI_SPECIFIC event. | |
| virtual bool | usesAffectEntire () |
| Claim support for Kit AFFECT_ENTIRE editing. | |
| virtual MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) |
| Double-check that this MenuItem will work with the currently selected sound range. | |
| virtual void | endSession () |
| End an editing session with this menu item. | |
| virtual void | readCurrentValue () |
| Like readValueAgain, but does not redraw. | |
| virtual uint8_t | getIndexOfPatchedParamToBlink () |
| virtual deluge::modulation::params::Kind | getParamKind () |
| virtual uint32_t | getParamIndex () |
| virtual uint8_t | shouldBlinkPatchingSourceShortcut (PatchSource s, uint8_t *colour) |
| virtual MenuItem * | patchingSourceShortcutPress (PatchSource s, bool previousPressStillActive=false) |
| Action to take when a source shortcut is pressed. | |
| virtual void | learnKnob (MIDICable *cable, int32_t whichKnob, int32_t modKnobMode, int32_t midiChannel) |
| virtual bool | allowsLearnMode () |
| Used by SoundEditor to determine if the current menu item can accept MIDI learning. | |
| virtual bool | learnNoteOn (MIDICable &cable, int32_t channel, int32_t noteCode) |
| Attempt to bind this menu item to a note code. | |
| virtual void | learnProgramChange (MIDICable &cable, int32_t channel, int32_t programNumber) |
| virtual void | learnCC (MIDICable &cable, int32_t channel, int32_t ccNumber, int32_t value) |
| virtual bool | shouldBlinkLearnLed () |
| virtual void | unlearnAction () |
| Unlearn the parameter controlled by this menu. | |
| virtual bool | isRangeDependent () |
| Returns true if this parameter is only relevant to some note ranges. | |
| virtual void | renderOLED () |
| Root rendering routine for OLED. | |
| virtual std::string_view | getTitle () const |
| Get the title to be used when rendering on OLED, both as a deluge::gui::menu_item::Submenu and when displaying ourselves (using the default renderOLED implementation). | |
| virtual void | drawName () |
| Draw the name we want to use when selecting this in a deluge::gui::menu_item::Submenu to the 7SEG. | |
| virtual std::string_view | getName () const |
| Get the actual name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| virtual bool | isRelevant (ModControllableAudio *modControllable, int32_t whichThing) |
| Check if this MenuItem should show up in a containing deluge::gui::menu_item::Submenu. | |
| virtual bool | shouldEnterSubmenu () |
| Check if selecting this menu item (with select encoder) should enter a submenu. | |
| virtual int32_t | getSubmenuItemTypeRenderLength () |
| Handle rendering of submenu item types. | |
| virtual int32_t | getSubmenuItemTypeRenderIconStart () |
| virtual bool | isSubmenu () |
| virtual void | setupNumberEditor () |
| virtual void | updatePadLights () |
| virtual void | getColumnLabel (StringBuf &label) |
| virtual bool | showColumnLabel () const |
| Show a label for the parameter in Horizontal menu. | |
| virtual int32_t | getColumnSpan () const |
| Get the number of occupied virtual columns in Horizontal menu. | |
| virtual bool | showNotification () const |
| Show a popup with the full name and value of the editing parameter at the top of Horizontal menu. | |
| virtual bool | allowToBeginSessionFromHorizontalMenu () |
| Allow entering menu session by selecting the menu item twice in Horizontal menu. | |
Protected Member Functions | |
| void | getShortOption (StringBuf &) override |
| void | getNotificationValue (StringBuf &) override |
| Get the parameter value string to show in the popup. | |
| Protected Member Functions inherited from deluge::gui::menu_item::Value< int32_t > | |
| virtual void | writeCurrentValue () |
Additional Inherited Members | |
| static void | drawItemsForOled (std::span< std::string_view > options, int32_t selectedOption, int32_t offset=0) |
| Internal helper which can draw the standard deluge::gui::menu_item::Submenu layout. | |
| deluge::l10n::String | title |
| Can get overridden by getTitle(). Actual max num chars for OLED display is 14. | |
| const deluge::l10n::String | name |
| Default name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| deluge::gui::menu_item::HorizontalMenu * | parent {nullptr} |
|
overridevirtual |
Paints the pixels below the standard title block.
Implements deluge::gui::menu_item::Enumeration.
|
overridevirtual |
Reimplemented from deluge::gui::menu_item::Enumeration.
|
overrideprotectedvirtual |
Get the parameter value string to show in the popup.
Needs to be overridden
Reimplemented from deluge::gui::menu_item::Enumeration.
Reimplemented in deluge::gui::menu_item::stutter::StutterDirection.
|
overrideprotectedvirtual |
Subclasses should implement this to provide a string suitable for using in a horizontal menu. Writes to a buffer instead of returning a value, since some subclasses (SyncLevel) must generate their option names. Default implementation renders the current value as number.
Reimplemented from deluge::gui::menu_item::Enumeration.
|
overridevirtual |
Reimplemented from MenuItem.
|
inlineoverridevirtual |
Handle a select button press.
Reimplemented from MenuItem.
Reimplemented in deluge::gui::menu_item::mpe::ZoneSelector, and deluge::gui::menu_item::osc::Type.
|
inlineoverridevirtual |
Get the "draw dot state".
This is a bitfield representation of which segments on the 7seg should have their '.' lit up.
The upper 4 bits determine how the lower 4 are interpreted. If the upper 4 bits are...
Reimplemented from MenuItem.
|
inlineoverridevirtual |
Implements deluge::gui::menu_item::Enumeration.
