Public Member Functions | |
| void | writeCurrentValue () override |
| bool | showColumnLabel () const override |
| Show a label for the parameter in Horizontal menu. | |
| void | renderInHorizontalMenu (int32_t startX, int32_t width, int32_t startY, int32_t height) override |
| Public Member Functions inherited from deluge::gui::menu_item::patch_cable_strength::Fixed | |
| Fixed (l10n::String newName, int32_t newP=0, PatchSource newS=PatchSource::LFO_GLOBAL_1) | |
| MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) final |
| uint8_t | shouldBlinkPatchingSourceShortcut (PatchSource s, uint8_t *colour) final |
| MenuItem * | patchingSourceShortcutPress (PatchSource s, bool previousPressStillActive) final |
| Action to take when a source shortcut is pressed. | |
| Public Member Functions inherited from deluge::gui::menu_item::patch_cable_strength::Regular | |
| ParamDescriptor | getDestinationDescriptor () final |
| PatchSource | getS () final |
| ParamDescriptor | getLearningThing () final |
| MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) override |
| uint8_t | shouldBlinkPatchingSourceShortcut (PatchSource s, uint8_t *colour) override |
| MenuItem * | patchingSourceShortcutPress (PatchSource s, bool previousPressStillActive) override |
| Action to take when a source shortcut is pressed. | |
| Public Member Functions inherited from deluge::gui::menu_item::PatchCableStrength | |
| void | beginSession (MenuItem *navigatedBackwardFrom) final |
| Begin an editing session with this menu item. | |
| void | endSession () final |
| End an editing session with this menu item. | |
| void | readCurrentValue () final |
| Like readValueAgain, but does not redraw. | |
| int32_t | getMinValue () const final |
| int32_t | getMaxValue () const final |
| int32_t | getNumDecimalPlaces () const final |
| virtual int32_t | getDefaultEditPos () |
| MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) override |
| uint8_t | getIndexOfPatchedParamToBlink () final |
| MenuItem * | selectButtonPress () final |
| Handle a select button press. | |
| ActionResult | buttonAction (hid::Button b, bool on, bool inCardRoutine) override |
| Handle an arbitrary button. | |
| void | selectEncoderAction (int32_t offset) override |
| Handle select encoder movement. | |
| void | horizontalEncoderAction (int32_t offset) override |
| Handle horizontal encoder movement. | |
| modulation::params::Kind | getParamKind () |
| uint32_t | getParamIndex () |
| PatchSource | getPatchSource () override |
| void | renderOLED () override |
| Root rendering routine for OLED. | |
| void | appendAdditionalDots (std::vector< uint8_t > &dotPositions) override |
| void | unlearnAction () final |
| Unlearn the parameter controlled by this menu. | |
| bool | allowsLearnMode () final |
| Used by SoundEditor to determine if the current menu item can accept MIDI learning. | |
| void | learnKnob (MIDICable *cable, int32_t whichKnob, int32_t modKnobMode, int32_t midiChannel) final |
| ModelStackWithAutoParam * | getModelStackWithParam (void *memory) override |
| void | updateAutomationViewParameter () override |
| Public Member Functions inherited from deluge::gui::menu_item::Decimal | |
| NumberStyle | getNumberStyle () const override |
| Public Member Functions inherited from deluge::gui::menu_item::Number | |
| void | drawHorizontalBar (int32_t yTop, int32_t marginL, int32_t marginR=-1, int32_t height=8) |
| Public Member Functions inherited from deluge::gui::menu_item::Value< int32_t > | |
| MenuItem () | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| void | beginSession (MenuItem *navigatedBackwardFrom) override |
| Begin an editing session with this menu item. | |
| void | selectEncoderAction (int32_t offset) override |
| Handle select encoder movement. | |
| void | readValueAgain () override |
| Re-read the value from the system and redraw the display to match. | |
| bool | selectEncoderActionEditsInstrument () final |
| Used by the sound editor to mark the current instrument as edited when the select encoder is scrolled. | |
| void | setValue (int32_t value) |
| int32_t | getValue () |
| Public Member Functions inherited from MenuItem | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| MenuItem & | operator= (const MenuItem &other)=delete |
| MenuItem & | operator= (const MenuItem &&other)=delete |
| virtual void | verticalEncoderAction (int32_t offset) |
| Handle vertical encoder movement. | |
| virtual ActionResult | timerCallback () |
| Handle a TimerName::UI_SPECIFIC event. | |
| virtual bool | usesAffectEntire () |
| Claim support for Kit AFFECT_ENTIRE editing. | |
| virtual MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) |
| Double-check that this MenuItem will work with the currently selected sound range. | |
| virtual bool | learnNoteOn (MIDICable &cable, int32_t channel, int32_t noteCode) |
| Attempt to bind this menu item to a note code. | |
| virtual void | learnProgramChange (MIDICable &cable, int32_t channel, int32_t programNumber) |
| virtual void | learnCC (MIDICable &cable, int32_t channel, int32_t ccNumber, int32_t value) |
| virtual bool | shouldBlinkLearnLed () |
| virtual bool | isRangeDependent () |
| Returns true if this parameter is only relevant to some note ranges. | |
| virtual std::string_view | getTitle () const |
| Get the title to be used when rendering on OLED, both as a deluge::gui::menu_item::Submenu and when displaying ourselves (using the default renderOLED implementation). | |
| virtual uint8_t | shouldDrawDotOnName () |
| Get the "draw dot state". | |
| virtual void | drawName () |
| Draw the name we want to use when selecting this in a deluge::gui::menu_item::Submenu to the 7SEG. | |
| virtual std::string_view | getName () const |
| Get the actual name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| virtual bool | isRelevant (ModControllableAudio *modControllable, int32_t whichThing) |
| Check if this MenuItem should show up in a containing deluge::gui::menu_item::Submenu. | |
| virtual bool | shouldEnterSubmenu () |
| Check if selecting this menu item (with select encoder) should enter a submenu. | |
| virtual int32_t | getSubmenuItemTypeRenderLength () |
| Handle rendering of submenu item types. | |
| virtual int32_t | getSubmenuItemTypeRenderIconStart () |
| virtual void | renderSubmenuItemTypeForOled (int32_t yPixel) |
| virtual bool | isSubmenu () |
| virtual void | setupNumberEditor () |
| virtual void | updatePadLights () |
| virtual void | getColumnLabel (StringBuf &label) |
| virtual int32_t | getColumnSpan () const |
| Get the number of occupied virtual columns in Horizontal menu. | |
| virtual bool | showNotification () const |
| Show a popup with the full name and value of the editing parameter at the top of Horizontal menu. | |
| virtual bool | allowToBeginSessionFromHorizontalMenu () |
| Allow entering menu session by selecting the menu item twice in Horizontal menu. | |
| Public Member Functions inherited from MenuItemWithCCLearning | |
| void | unlearnAction () |
| bool | allowsLearnMode () const |
| void | learnKnob (MIDICable *cable, int32_t whichKnob, int32_t modKnobMode, int32_t midiChannel) |
| Public Member Functions inherited from deluge::gui::menu_item::Automation | |
| MenuItem * | selectButtonPress () |
| ActionResult | buttonAction (deluge::hid::Button b, bool on, bool inCardRoutine) |
| void | selectAutomationViewParameter (bool clipMinder) |
| void | handleAutomationViewParameterUpdate () |
| MenuItem::updateAutomationViewParameter forwards here when necessary. | |
Additional Inherited Members | |
| static void | drawItemsForOled (std::span< std::string_view > options, int32_t selectedOption, int32_t offset=0) |
| Internal helper which can draw the standard deluge::gui::menu_item::Submenu layout. | |
| Public Attributes inherited from deluge::gui::menu_item::PatchCableStrength | |
| uint32_t | delayHorizontalScrollUntil = 0 |
| Used when scrolling horizontally to briefly catch on min / max decimal number edit position. | |
| deluge::l10n::String | title |
| Can get overridden by getTitle(). Actual max num chars for OLED display is 14. | |
| const deluge::l10n::String | name |
| Default name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| deluge::gui::menu_item::HorizontalMenu * | parent {nullptr} |
| Protected Member Functions inherited from deluge::gui::menu_item::PatchCableStrength | |
| ModelStackWithAutoParam * | getModelStack (void *memory, bool allowCreation=false) |
| void | getNotificationValue (StringBuf &valueBuf) override |
| Get the parameter value string to show in the popup. | |
| Protected Member Functions inherited from deluge::gui::menu_item::Decimal | |
| void | drawValue () override |
| virtual int32_t | getDefaultEditPos () const |
| virtual int32_t | getNumberEditSize () |
| void | drawPixelsForOled () override |
| Paints the pixels below the standard title block. | |
| virtual void | drawActualValue (bool justDidHorizontalScroll=false) |
| Protected Member Functions inherited from deluge::gui::menu_item::Number | |
| float | getNormalizedValue () |
| void | drawKnob (int32_t startX, int32_t startY, int32_t width, int32_t height) |
| void | drawVerticalBar (int32_t startX, int32_t startY, int32_t slotWidth, int32_t slotHeight) |
| void | drawLevel (int32_t startX, int32_t startY, int32_t slotWidth, int32_t slotHeight) |
| void | drawPercent (int32_t startX, int32_t startY, int32_t width, int32_t height) |
| void | drawSlider (int32_t startX, int32_t startY, int32_t slotWidth, int32_t slotHeight) |
| void | drawLengthSlider (int32_t startX, int32_t startY, int32_t slotWidth, int32_t slotHeight, bool minSliderPos=3) |
| Static Protected Member Functions inherited from deluge::gui::menu_item::Decimal | |
| static int32_t | getNumNonZeroDecimals (int32_t value) |
| Protected Attributes inherited from deluge::gui::menu_item::patch_cable_strength::Fixed | |
| uint8_t | p |
| PatchSource | s |
|
inlineoverridevirtual |
Reimplemented from deluge::gui::menu_item::Decimal.
|
inlineoverridevirtual |
Show a label for the parameter in Horizontal menu.
true by default, but can be overridden
Reimplemented from MenuItem.
|
inlineoverridevirtual |
Reimplemented from deluge::gui::menu_item::PatchCableStrength.
