Public Member Functions | |
| FileSelector (l10n::String newName, uint8_t sourceId) | |
| void | beginSession (MenuItem *navigatedBackwardFrom) override |
| Begin an editing session with this menu item. | |
| bool | isRelevant (ModControllableAudio *modControllable, int32_t whichThing) override |
| Check if this MenuItem should show up in a containing deluge::gui::menu_item::Submenu. | |
| MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) override |
| bool | allowToBeginSessionFromHorizontalMenu () override |
| Allow entering menu session by selecting the menu item twice in Horizontal menu. | |
| void | renderInHorizontalMenu (int32_t startX, int32_t width, int32_t startY, int32_t height) override |
| void | getColumnLabel (StringBuf &label) override |
| Public Member Functions inherited from MenuItem | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| MenuItem & | operator= (const MenuItem &other)=delete |
| MenuItem & | operator= (const MenuItem &&other)=delete |
| virtual ActionResult | buttonAction (deluge::hid::Button b, bool on, bool inCardRoutine) |
| Handle an arbitrary button. | |
| virtual void | horizontalEncoderAction (int32_t offset) |
| Handle horizontal encoder movement. | |
| virtual void | verticalEncoderAction (int32_t offset) |
| Handle vertical encoder movement. | |
| virtual void | selectEncoderAction (int32_t offset) |
| Handle select encoder movement. | |
| virtual bool | selectEncoderActionEditsInstrument () |
| Used by the sound editor to mark the current instrument as edited when the select encoder is scrolled. | |
| virtual MenuItem * | selectButtonPress () |
| Handle a select button press. | |
| virtual ActionResult | timerCallback () |
| Handle a TimerName::UI_SPECIFIC event. | |
| virtual bool | usesAffectEntire () |
| Claim support for Kit AFFECT_ENTIRE editing. | |
| virtual MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) |
| Double-check that this MenuItem will work with the currently selected sound range. | |
| virtual void | endSession () |
| End an editing session with this menu item. | |
| virtual void | readValueAgain () |
| Re-read the value from the system and redraw the display to match. | |
| virtual void | readCurrentValue () |
| Like readValueAgain, but does not redraw. | |
| virtual uint8_t | getIndexOfPatchedParamToBlink () |
| virtual deluge::modulation::params::Kind | getParamKind () |
| virtual uint32_t | getParamIndex () |
| virtual uint8_t | shouldBlinkPatchingSourceShortcut (PatchSource s, uint8_t *colour) |
| virtual MenuItem * | patchingSourceShortcutPress (PatchSource s, bool previousPressStillActive=false) |
| Action to take when a source shortcut is pressed. | |
| virtual void | learnKnob (MIDICable *cable, int32_t whichKnob, int32_t modKnobMode, int32_t midiChannel) |
| virtual bool | allowsLearnMode () |
| Used by SoundEditor to determine if the current menu item can accept MIDI learning. | |
| virtual bool | learnNoteOn (MIDICable &cable, int32_t channel, int32_t noteCode) |
| Attempt to bind this menu item to a note code. | |
| virtual void | learnProgramChange (MIDICable &cable, int32_t channel, int32_t programNumber) |
| virtual void | learnCC (MIDICable &cable, int32_t channel, int32_t ccNumber, int32_t value) |
| virtual bool | shouldBlinkLearnLed () |
| virtual void | unlearnAction () |
| Unlearn the parameter controlled by this menu. | |
| virtual bool | isRangeDependent () |
| Returns true if this parameter is only relevant to some note ranges. | |
| virtual void | renderOLED () |
| Root rendering routine for OLED. | |
| virtual void | drawPixelsForOled () |
| Paints the pixels below the standard title block. | |
| virtual std::string_view | getTitle () const |
| Get the title to be used when rendering on OLED, both as a deluge::gui::menu_item::Submenu and when displaying ourselves (using the default renderOLED implementation). | |
| virtual uint8_t | shouldDrawDotOnName () |
| Get the "draw dot state". | |
| virtual void | drawName () |
| Draw the name we want to use when selecting this in a deluge::gui::menu_item::Submenu to the 7SEG. | |
| virtual std::string_view | getName () const |
| Get the actual name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| virtual bool | shouldEnterSubmenu () |
| Check if selecting this menu item (with select encoder) should enter a submenu. | |
| virtual int32_t | getSubmenuItemTypeRenderLength () |
| Handle rendering of submenu item types. | |
| virtual int32_t | getSubmenuItemTypeRenderIconStart () |
| virtual void | renderSubmenuItemTypeForOled (int32_t yPixel) |
| virtual bool | isSubmenu () |
| virtual void | setupNumberEditor () |
| virtual void | updatePadLights () |
| virtual void | updateAutomationViewParameter () |
| virtual bool | showColumnLabel () const |
| Show a label for the parameter in Horizontal menu. | |
| virtual int32_t | getColumnSpan () const |
| Get the number of occupied virtual columns in Horizontal menu. | |
| virtual bool | showNotification () const |
| Show a popup with the full name and value of the editing parameter at the top of Horizontal menu. | |
| virtual void | getNotificationValue (StringBuf &valueBuf) |
| Get the parameter value string to show in the popup. | |
Static Private Member Functions | |
| static std::string | getLastFolderFromPath (String &path) |
Private Attributes | |
| uint8_t | sourceId_ |
Additional Inherited Members | |
| static void | drawItemsForOled (std::span< std::string_view > options, int32_t selectedOption, int32_t offset=0) |
| Internal helper which can draw the standard deluge::gui::menu_item::Submenu layout. | |
| deluge::l10n::String | title |
| Can get overridden by getTitle(). Actual max num chars for OLED display is 14. | |
| const deluge::l10n::String | name |
| Default name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| deluge::gui::menu_item::Submenu * | parent {nullptr} |
|
inlinenodiscardoverridevirtual |
Allow entering menu session by selecting the menu item twice in Horizontal menu.
false by default, but can be overridden
Reimplemented from MenuItem.
|
overridevirtual |
Begin an editing session with this menu item.
Should make sure the menu's internal state matches the system and redraw the display.
Reimplemented from MenuItem.
|
overridevirtual |
Reimplemented from MenuItem.
|
overridevirtual |
Check if this MenuItem should show up in a containing deluge::gui::menu_item::Submenu.
| sound | Sound we would edit if we were to be entered. |
| whichThing | Source index within the sound. Usually ignored, but matters for e.g. oscillator and FM modulator parameters. |
Reimplemented from MenuItem.
|
overridevirtual |
Reimplemented from MenuItem.
