Public Member Functions | |
| ParamDescriptor | getDestinationDescriptor () override |
| MenuItem * | selectButtonPress () override |
| Handle a select button press. | |
| MenuItem * | patchingSourceShortcutPress (PatchSource newS, bool previousPressStillActive) override |
| Action to take when a source shortcut is pressed. | |
| std::string_view | getTitle () const override |
| Get the title to be used when rendering on OLED, both as a deluge::gui::menu_item::Submenu and when displaying ourselves (using the default renderOLED implementation). | |
 Public Member Functions inherited from deluge::gui::menu_item::SourceSelection | |
| void | beginSession (MenuItem *navigatedBackwardFrom=nullptr) override |
| Begin an editing session with this menu item. | |
| void | selectEncoderAction (int32_t offset) final |
| Handle select encoder movement. | |
| uint8_t | getIndexOfPatchedParamToBlink () final |
| uint8_t | shouldBlinkPatchingSourceShortcut (PatchSource s, uint8_t *colour) final |
| void | readValueAgain () final |
| Re-read the value from the system and redraw the display to match. | |
| void | drawPixelsForOled () |
| Paints the pixels below the standard title block. | |
| void | drawValue () override |
| Public Member Functions inherited from deluge::gui::menu_item::Value< int32_t > | |
| MenuItem () | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| void | beginSession (MenuItem *navigatedBackwardFrom) override |
| Begin an editing session with this menu item. | |
| void | selectEncoderAction (int32_t offset) override |
| Handle select encoder movement. | |
| void | readValueAgain () override |
| Re-read the value from the system and redraw the display to match. | |
| bool | selectEncoderActionEditsInstrument () final |
| Used by the sound editor to mark the current instrument as edited when the select encoder is scrolled. | |
| void | setValue (int32_t value) |
| void | setValue (E value) |
| int32_t | getValue () |
| E | getValue () |
| MenuItem () | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| Public Member Functions inherited from MenuItem | |
| MenuItem (deluge::l10n::String newName, deluge::l10n::String newTitle=deluge::l10n::String::EMPTY_STRING) | |
| MenuItem (const MenuItem &other)=delete | |
| MenuItem (const MenuItem &&other)=delete | |
| MenuItem & | operator= (const MenuItem &other)=delete |
| MenuItem & | operator= (const MenuItem &&other)=delete |
| virtual ActionResult | buttonAction (deluge::hid::Button b, bool on, bool inCardRoutine) |
| Handle an arbitrary button. | |
| virtual void | horizontalEncoderAction (int32_t offset) |
| Handle horizontal encoder movement. | |
| virtual void | verticalEncoderAction (int32_t offset) |
| Handle vertical encoder movement. | |
| virtual ActionResult | timerCallback () |
| Handle a TimerName::UI_SPECIFIC event. | |
| virtual bool | usesAffectEntire () |
| Claim support for Kit AFFECT_ENTIRE editing. | |
| virtual MenuPermission | checkPermissionToBeginSession (ModControllableAudio *modControllable, int32_t whichThing, MultiRange **currentRange) |
| Double-check that this MenuItem will work with the currently selected sound range. | |
| virtual void | readCurrentValue () |
| Like readValueAgain, but does not redraw. | |
| virtual deluge::modulation::params::Kind | getParamKind () |
| virtual uint32_t | getParamIndex () |
| virtual void | learnKnob (MIDICable *cable, int32_t whichKnob, int32_t modKnobMode, int32_t midiChannel) |
| virtual bool | allowsLearnMode () |
| Used by SoundEditor to determine if the current menu item can accept MIDI learning. | |
| virtual bool | learnNoteOn (MIDICable &cable, int32_t channel, int32_t noteCode) |
| Attempt to bind this menu item to a note code. | |
| virtual void | learnProgramChange (MIDICable &cable, int32_t channel, int32_t programNumber) |
| virtual void | learnCC (MIDICable &cable, int32_t channel, int32_t ccNumber, int32_t value) |
| virtual bool | shouldBlinkLearnLed () |
| virtual void | unlearnAction () |
| Unlearn the parameter controlled by this menu. | |
| virtual bool | isRangeDependent () |
| Returns true if this parameter is only relevant to some note ranges. | |
| virtual void | renderOLED () |
| Root rendering routine for OLED. | |
| virtual uint8_t | shouldDrawDotOnName () |
| Get the "draw dot state". | |
| virtual void | drawName () |
| Draw the name we want to use when selecting this in a deluge::gui::menu_item::Submenu to the 7SEG. | |
| virtual std::string_view | getName () const |
| Get the actual name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| virtual void | getColumnLabel (StringBuf &label) |
| Get the name for use on horizontal menus. | |
| virtual bool | isRelevant (ModControllableAudio *modControllable, int32_t whichThing) |
| Check if this MenuItem should show up in a containing deluge::gui::menu_item::Submenu. | |
| virtual bool | shouldEnterSubmenu () |
| Check if selecting this menu item (with select encoder) should enter a submenu. | |
| virtual int32_t | getSubmenuItemTypeRenderLength () |
| Handle rendering of submenu item types. | |
| virtual int32_t | getSubmenuItemTypeRenderIconStart () |
| virtual void | renderSubmenuItemTypeForOled (int32_t yPixel) |
| virtual void | renderInHorizontalMenu (int32_t startX, int32_t width, int32_t startY, int32_t height) |
| virtual bool | isSubmenu () |
| virtual void | setupNumberEditor () |
| virtual void | updatePadLights () |
| virtual void | updateAutomationViewParameter () |
| void | renderColumnLabel (int32_t startX, int32_t width, int32_t startY) |
Additional Inherited Members | |
| static void | drawItemsForOled (std::span< std::string_view > options, int32_t selectedOption, int32_t offset=0) |
| Internal helper which can draw the standard deluge::gui::menu_item::Submenu layout. | |
| Public Attributes inherited from deluge::gui::menu_item::SourceSelection | |
| int32_t | scrollPos |
| PatchSource | s |
| deluge::l10n::String | title |
| Can get overridden by getTitle(). Actual max num chars for OLED display is 14. | |
| const deluge::l10n::String | name |
| Default name for use on OLED for deluge::gui::menu_item::Submenu s. | |
| Static Public Attributes inherited from deluge::gui::menu_item::SourceSelection | |
| static int32_t | selectedRowOnScreen |
| Protected Member Functions inherited from deluge::gui::menu_item::SourceSelection | |
| bool | sourceIsAllowed (PatchSource source) |
| uint8_t | shouldDrawDotOnValue () |
| Protected Member Functions inherited from deluge::gui::menu_item::Value< int32_t > | |
| virtual void | writeCurrentValue () |
|
overridevirtual |
Implements deluge::gui::menu_item::SourceSelection.
|
inlineoverridevirtual |
Get the title to be used when rendering on OLED, both as a deluge::gui::menu_item::Submenu and when displaying ourselves (using the default renderOLED implementation).
If not overridden, defaults to returning title.
The returned pointer must live long enough for us to draw the title, which for practical purposes means "the lifetime of this menu item"
Reimplemented from MenuItem.
|
overridevirtual |
Action to take when a source shortcut is pressed.
Potentially reconfigures some SoundEditor state so patching will work.
| s | The source being pressed. |
| previousPressStillActive | True if there is another patch source press still active. Useful to set up cable strength modulation. |
NO_NAVIGATION if the SoundEditor should ask the menu 1 layer up in the stack what to donullptr if nothing should happenReimplemented from MenuItem.
|
overridevirtual |
Handle a select button press.
NO_NAVIGATION if the SoundEditor should stay on the current menu.nullptr if the SoundEditor should go up one level in the menu stack.Reimplemented from MenuItem.
