deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano Class Reference

Inheritance diagram for deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano:

Collaboration diagram for deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano:

Public Member Functions
void	evaluatePads (PressedPad presses[kMaxNumKeyboardPadPresses]) override
	Handle input pad presses.
void	handleVerticalEncoder (int32_t offset) override
	Shift state not supplied since that function is already taken.
void	handleHorizontalEncoder (int32_t offset, bool shiftEnabled, PressedPad presses[kMaxNumKeyboardPadPresses], bool encoderPressed=false) override
	Will be called with offset 0 to recalculate bounds on clip changes.
void	precalculate () override
	This function is called on visibility change and if colour offset changes.
void	renderPads (RGB image[][kDisplayWidth+kSideBarWidth]) override
	Handle output.
l10n::String	name () override
bool	supportsInstrument () override
	This currently includes Synth, MIDI and CV.
bool	supportsKit () override
Public Member Functions inherited from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard
void	enableNote (uint8_t note, uint8_t velocity)
bool	verticalEncoderHandledByColumns (int32_t offset)
bool	horizontalEncoderHandledByColumns (int32_t offset, bool shiftEnabled)
ColumnControlFunction	nextControlFunction (ColumnControlFunction cur, ColumnControlFunction skip)
ColumnControlFunction	prevControlFunction (ColumnControlFunction cur, ColumnControlFunction skip)
ColumnControlFunction	stepControlFunction (int32_t offset, ColumnControlFunction cur, ColumnControlFunction skip)
void	renderSidebarPads (RGB image[][kDisplayWidth+kSideBarWidth]) override
void	checkNewInstrument (Instrument *newInstrument) override
void	renderColumnBeatRepeat (RGB image[][kDisplayWidth+kSideBarWidth], int32_t column)
Public Member Functions inherited from deluge::gui::ui::keyboard::KeyboardLayout
virtual RequiredScaleMode	requiredScaleMode ()
virtual NotesState &	getNotesState ()

Private Member Functions
uint16_t	intervalFromCoords (int32_t x, int32_t y)
uint16_t	noteFromCoords (int32_t x, int32_t y)

Private Attributes
RGB	noteColours [totalPianoOctaves+1]

Additional Inherited Members
Public Attributes inherited from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard
int8_t	leftColHeld = -1
int8_t	rightColHeld = -1
Public Attributes inherited from deluge::gui::ui::keyboard::KeyboardLayout
uint8_t	velocity = 64
Protected Member Functions inherited from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard
virtual bool	allowSidebarType (ColumnControlFunction sidebarType)
Protected Member Functions inherited from deluge::gui::ui::keyboard::KeyboardLayout
bool	isKit ()
int16_t	getRootNote ()
	Song root note can be in any octave, layouts get the normalized one.
bool	getScaleModeEnabled ()
uint8_t	getScaleNoteCount ()
NoteSet &	getScaleNotes ()
uint8_t	getDefaultVelocity ()
int32_t	getLowestClipNote ()
int32_t	getHighestClipNote ()
RGB	getNoteColour (uint8_t note)
NoteHighlightIntensity &	getHighlightedNotes ()
NoteHighlightIntensity &	getNornsNotes ()
KeyboardState &	getState ()
Protected Attributes inherited from deluge::gui::ui::keyboard::KeyboardLayout
NotesState	currentNotesState

Member Function Documentation

evaluatePads()

void deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::evaluatePads ( PressedPad presses[kMaxNumKeyboardPadPresses] )

overridevirtual

Handle input pad presses.

Reimplemented from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard.

handleHorizontalEncoder()

void deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::handleHorizontalEncoder ( int32_t offset, bool shiftEnabled, PressedPad presses[kMaxNumKeyboardPadPresses], bool encoderPressed = false )

overridevirtual

Will be called with offset 0 to recalculate bounds on clip changes.

Reimplemented from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard.

handleVerticalEncoder()

void deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::handleVerticalEncoder ( int32_t offset )

overridevirtual

Shift state not supplied since that function is already taken.

Reimplemented from deluge::gui::ui::keyboard::layout::ColumnControlsKeyboard.

name()

l10n::String deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::name ( )

inlineoverridevirtual

Implements deluge::gui::ui::keyboard::KeyboardLayout.

precalculate()

void deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::precalculate ( )

overridevirtual

This function is called on visibility change and if colour offset changes.

Implements deluge::gui::ui::keyboard::KeyboardLayout.

renderPads()

void deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::renderPads ( RGB image[][kDisplayWidth+kSideBarWidth] )

overridevirtual

Handle output.

Reimplemented from deluge::gui::ui::keyboard::KeyboardLayout.

supportsInstrument()

bool deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::supportsInstrument ( )

inlineoverridevirtual

This currently includes Synth, MIDI and CV.

Reimplemented from deluge::gui::ui::keyboard::KeyboardLayout.

supportsKit()

bool deluge::gui::ui::keyboard::layout::KeyboardLayoutPiano::supportsKit ( )

inlineoverridevirtual

Reimplemented from deluge::gui::ui::keyboard::KeyboardLayout.

---

The documentation for this class was generated from the following files:

• src/deluge/gui/ui/keyboard/layout/piano.h
• src/deluge/gui/ui/keyboard/layout/piano.cpp
